Refrigerated Vehicles


XKC5031XLC6B
A chassis cab truck is a commercial vehicle, and it's more basic than the pickup, with fewer features available. Its capabilities are designed for function, especially transporting heavy materials. The front looks about the same as the pickup, but the rear has a reinforced platform instead of a boxed pickup bed.
XKC5031XLC6B
Features
Product Specifications
ONLINE SERVICE
Features
1
Responsible for Yan Xing
This model is specially developed for "vaccination" stage to ensure cold-chain transportation of vaccines throughout,
2
Responsible for Yan Xing
This model is specially developed for "vaccination" stage to ensure cold-chain transportation of vaccines throughout,
3
Responsible for Yan Xing
This model is specially developed for "vaccination" stage to ensure cold-chain transportation of vaccines throughout,
4
Responsible for Yan Xing
This model is specially developed for "vaccination" stage to ensure cold-chain transportation of vaccines throughout,
Calm operation adds points for convenience
Cutaway van chassis are similar vehicles, but have specific components at the rear whereas chassis cabs usually do not have additional components.
Product Specifications
Refitted Vehicle Main Technical Specifications
Vehicle Model: XKC5031XLC6B
Vehicle Type Mini Truck
Vehicle Manufacturer AVIC Henan Xinfei Special Purpose Vehicle Co., Ltd.
Vehicle Brand AVIC XINFEI
Vehicle Overall Size  (LxWxH) mm 5080 1780 2490
Box Internal Size  (LxWxH) mm 3150 1630 1570
Box Volume 8.06
Panel Thickness mm 55~120
Interior/Outer FRP Lining   Food Grade, Light White
Insulation Material   PU
Insulation Material Density    40kg/m³ (bottom panel), 35kg/m³ (other panels)
Thermal Conductivity  W/m.K 0.023
GVW kg 3195
Curb Weight kg 2050
Payload Weight kg 1315
Fuel Consumption l/100km 9.8
Maximum Speed km/h 100
Rated Cab Passengers person 2
Front/Rear Suspension mm 1075/1255
Approach/Departure Angle 22/20
Chassis Manufacturer FOTON
Chassis Model BJ1031V5JV4-51
Transmission Type Manual
Engine Manufatcurer Ha'erbin Dong'an / Ha'erbin Dong'an
Engine Model DAM15KL / DAM16KL
Engine Power 85kW / 90kW
Fuel Type Gasoline
Emissoin Standard China VI
Steering Type LHD or RHD
Tyre Specification 175R14LT-8PR
Tyre QTY 6 pcs
Antilock Brake System (ABS) YES
Rear Door - standard Rear Swing Dual Doors
Options: 1. Checkered aluminum flooring & skirt plates;
2. Aluminum T-flooring & checkered aluminum skirt plates;
3. Side single door and/or dual doors;
4. Cargo side track, rails, shelves;
5. Aluminum-alloy meat hanging tracks & 304# stainless steel hooks;
6. Thermo King, Carrier, AVIC Xinfei, Yuhwa Thermo brands TR units.
7. Others.
